CFP series Hydrophobic PTFE membrane High-Temperature Sterilizing grade Hydrophobic PTFE Pleated Filter Cartridges
CFP series Hydrophobic PTFE membrane High-Temperature Sterilizing grade Pleated Filter Cartridges can ensure the sterilizing performance in different humidity environment. The oxidation resistant PP components offer superior oxidation and high temperature resistance, reinforced core makes the filter cartridge higher pressure resistance, withstand in-line steam sterilization and autoclave, it is suitable for fermentation, pharmaceutical and other biotechnology applications.
Applications
Process venting
Compressed air
Gas purification
Fermentation feed air
Features
Inherently hydrophobic PTFE membranes
High temperature resistance
Oxidation resistant hardware
High-flow and low pressure drop
Enhanced steaming resistance
100% Integrity tested
Dimension
| Out Diameter | 2.72” (69mm) |
|---|---|
| Length | 5” (125 mm) / 10” (254 mm) / 20” (500 mm) / 30” (750 mm) / 40” (1000 mm) |
Integrity Test Parameters
| Diffusion Flow (DF) | ≤ 20 ml/min @ 1035 mbar (60/40 IPA/Water) |
|---|---|
| Water Instrusion (WIT) | CFPPT0022U ≤ 0.38 ml/min @ 2500 mbar CFPPT0022T ≤ 0.75ml/min @ 2500 mbar |
Material of Constructions
| Media | PTFE |
|---|---|
| Support | PP/PET |
| Cage/End Cap | High temperature resistance PP |
| Core | High temperature resistance PP/SS |
| Adapter | PP with insert |
Pore Size
| Gas | 0.01 μm |
|---|---|
| Liquid | 0.2 μm |
Performance
| Max Operating Temperature | 100 °C |
|---|---|
| Max Operating DP | 5.2 bar @ 20 °C, 2.4 bar @ 80 °C |
Sterilization
| Inline Steam Sterilization | 135 °C / 30 min, 150 cycles dimension |
|---|---|
| Maximum Forward Steam Sterilization | 1 bar @ 135 °C, 0.3 bar @ 142 °C |
| Maximum Reverse Steam Sterilization | 0.5 bar @ 125 °C, 0.2 bar @ 142 °C |
Quality
Filter cartridges are manufacturered in a clean room environment
Manufacturered according to ISO9001:2015 certified Quality Management System
Materials of construction comply with FDA requlations for food and beverage contact use as detailed in the US Code of Federal Regulations 21 CFR
100% integrity tested
Each individual element is tracked by serial number
