Stainless Steel filter Stainless Steel Sintered filter cartridge
GVS Metal Sintered filter cartridge is a microporous filter media formed by high purity stainless steel powder or titanium poweder as raw material by high temperature and high vacuum sintering process.
The filter media has high porosity, good mechanical properties, excellent chemical compatibility, no shedding, extremely low dissolution. Filter can be repeatedly cleaned and reused with low operating cost.
Applications
Steam filtration
Filtration of corrosive reagents
High temperature fluid filtration
Liquid Decarburization filtration
Features
Tubular porous structure
Metal material has high mechanical strength and no media falling off
Good temperature resistancet
Washable and long-lasting
Dimension
| Out Diameter | 60mm, 65mm, 68mm |
|---|---|
| Length | 5",10",20" |
Material of Constructions
| Media | SS304/SS316L/Titanium |
|---|---|
| Core/Cage/Endcap | 304/316L |
| Seal | Silicone, EPDM, NBR, E-FKM |
Performance
| Media | SS304/SS316L/Titanium |
|---|---|
| Core/Cage/Endcap | 304/316L |
| Seal | Silicone, EPDM, NBR, E-FKM |
Quality
Manufactured according to ISO9001: 2015 certified Quality Management System
